Budrick 8500

Deliver trusted accuracy and streamlined cardiac diagnostics with the Burdick 8500 Digital ECG Machine. Engineered to provide healthcare practitioners with a clear, comfortable view of proven cardiac performance, this compact diagnostic device features an adjustable color widescreen display and cutting-edge algorithm analysis to optimize clinical workflows and improve patient care standards.

Channel Type & Configuration

●     12-Channel Diagnostic System: Utilizes a standard 12-lead acquisition format with flexible, user-selectable printing layouts. It displays and prints real-time cardiac waveforms in 3, 4, 6, or full 12-channel configurations to adapt instantly to diverse clinical assessment needs.

Key Features

●     Multi-Angle 7-Inch Color Screen: High-resolution widescreen display can be easily tilted to eliminate glare, allowing seamless previewing and real-time viewing of 3, 6, or 12 channels of crisp waveform data simultaneously.

●     Advanced Glasgow Interpretation Algorithm: Features the clinically proven Glasgow Royal Infirmary (GRI) analysis. It is the first algorithm to interpret cardiac data using five critical patient variables: age, gender, race, current medication, and classification for unmatched diagnostic precision.

●     AccuPrint™ Print Management: Built-in safeguards restrict thermal printing if the initial 10-second data quality is poor or compromised by artifact interference, completely eliminating paper waste and unnecessary retakes.

●     Seamless Digital Integration: Supports Ethernet connectivity out of the box with bidirectional electronic medical record (EMR/HIS) communication, reducing manual data entry errors and speeding up record access.

●     Durable Alphanumeric Keypad: Built with a smooth, easy-to-clean keyboard surface featuring dedicated, one-touch function keys and interactive on-screen QuickTips for minimal user training.

Technical Specifications

●     Waveform Display Options: Selectable 3-, 4-, 6-, or 12-channel printouts and screen configurations

●     Data Storage Capacity: Internal memory securely holds up to 300 complete digital ECG records

●     Pacer Detection Speed: High-speed data acquisition at 64,000 samples per second for precise pacemaker spike tracking

●     Print Formats & Media: Supports high-quality thermal printing on standard US letter (8.5 in x 11 in) or A4 paper sheets

●     Safety & Compliance: Meets international digital performance requirements of IEC 60601-2-51 with built-in defibrillation protection up to 5000V

Condition:  Excellent - Imported Pre Owned
