Welch Allyn CP 50

Maximize space and mobility without compromising diagnostic accuracy with the Welch Allyn CP 50 ECG Machine. This ultra-compact, lightweight device is engineered specifically for ambulatory clinics, private practices, and rapid-response settings, pairing an easy-to-use touchscreen with reliable automated testing to streamline primary cardiac care.

Channel Type & Configuration

●     12-Channel Diagnostic System: Simultaneously monitors and records all 12 standard leads, with user-defined screen views and print printouts available in flexible 3-, 6-, or 12-channel configurations to match your clinical testing preferences.

Key Features

●     4.3-Inch Color Touchscreen Display: Navigation is entirely touch-driven with an interactive, color user interface that guides clinical staff smoothly from hookup to printout.

●     MEANS ECG Interpretation Software: Employs the highly regarded MEANS interpretation algorithm to deliver immediate, computerized cardiac assessments for confident diagnostic verification.

●     Intelligent Lead Hookup Indicator: On-screen visual lead maps identify detached or poorly connected electrodes in real time, preventing failed tests and reducing paper consumption.

●     Ultra-Portable, Lightweight Body: Weighing under 2.5 kg, its small, sleek profile fits effortlessly onto small desks, specialized medical counters, or light rolling carts.

●     Instant Digital Output: Generates clean, secure digital records that transfer smoothly to external PCs or electronic medical record systems over standard connections.

Technical Specifications

●     Waveform Recording Speeds: Manual and automatic tracking speeds adjustable at 5, 10, 25, or 50 mm/s

●     Data Storage Capacity: Internal flash memory securely archives up to 25 unique patient records

●     Printer & Media Layout: Integrated high-resolution thermal array printer utilizing 110mm width roll paper

●     Power Supply: AC mains operation supported by an internal rechargeable lithium-ion battery pack

●     Compliance & Safety: Certified to international standards including IEC 60601-1-2 with comprehensive defibrillator shielding

Condition:  Excellent - Imported Pre Owned
